VP Series Valves
DYNEX VP PROPORTIONAL RELIEF VALVES
Max. Pressure to 15 000 psi (1040 bar).
Max. Flow to 1 gpm (3.7 L/min)
- VP Proportional valves are direct acting, poppet type relief valves.
- The VP provides reliable pressure control and circuit protection at pressures to 15 000 psi (1040 bar).
- Proportional models provide infinitely variable pressure settings up to the maximum pressure.
- These models let you remotely control the relief pressure setting, proportional to a variable electrical input signal
- (10 VDC or 24 VDC).
- Driver Provided Separately
Product Specifications
Model Code | Nominal Flow U.S. gpm | L/min | Max. Flow U.S. gpm | L/min | Max. Pressure psi | bar | |||
---|---|---|---|---|---|---|
VP10 | 0.7 | 2.6 | 1 | 0.4 | 10 000 | 700 |
VP15 | 0.7 | 2.6 | 1 | 0.4 | 15 000 | 1040 |
Literature

VP Series Valves – Engineering Specifications
1 file(s) 2.91 MB
3D Model

VP-HP03-10
1 file(s) 3.94 MB
